Product Brochure

HDPE SOCKET END PIPE

Name: HDPE SOCKET END PIPE
Brand: ELEGANT POLYMERS
Price: 40 INR
Availability: InStock

40 INR/Meter

Get a Price/Quote

Product Details:

Pipe Type Round
Working Presssure 2.5 kg/cm2 to 20 kg/cm2
Usage Water Supply, Dranainge , Pipe line
Feature UV Resistance , Crush Resistance , Heavy Material Quolity
Pressure 2.5 kg/cm2 to 20 kg/cm2 kgf/cm2
Fittings Flanges, Valves
Shape Round
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

HDPE SOCKET END PIPE Price And Quantity

Price 40 INR/Meter
Minimum Order Quantity 750 Meter

HDPE SOCKET END PIPE Product Specifications

Port Size 16mm to 630mm
Life Span 40 yrs
Application Water Supply, Dranainge , Pipe line
Weight 1 kg. to 170 kg. Kilograms (kg)
Thread Type BSP
Product Type HDPE Underground Pipe
Material Grade PE63 , PE80, PE100
Warranty 5 yrs
Standard IS 4984:2016, IS 14333:1996, IS 14151(Pt-2):2008, DIN 8074, DIN 8075, ISO 4427
Diameter 16mm to 630mm Meter (m)
Material HDPE
Pressure Ratings 2.5 kg/cm2 to 20 kg/cm2
Color Black
Thickness 1.90 to 120.80 Millimeter (mm)
Working Presssure 2.5 kg/cm2 to 20 kg/cm2
Connection Type Other
Pipe Type Round
Feature UV Resistance , Crush Resistance , Heavy Material Quolity
Usage Water Supply, Dranainge , Pipe line
Pressure 2.5 kg/cm2 to 20 kg/cm2 kgf/cm2
Fittings Flanges, Valves
Length 6/12 Coils Meter (m)
Shape Round
Corrosion Resistant yes

HDPE SOCKET END PIPE Trade Information

FOB Port mundra port
Payment Terms Cash Advance (CA), Cash in Advance (CID), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C)
Supply Ability 800000 Meter Per Year
Delivery Time 1 Week
Sample Available No
Sample Policy Free samples available with shipping and taxes paid by the buyer
Main Export Market(s) Asia, Australia, South America, Eastern Europe, Western Europe, Middle East, Africa, North America, Central America
Main Domestic Market All India
Certifications IS 4984:2016, IS 14333:1996, IS 14151(Pt-2):2008, DIN 8074, DIN 8075, ISO 4427

Product Description

An ElegsntHDPE socket pipe end refers to a High-Density Polyethylene pipe or fitting that is manufactured with a socket-shaped end (female end), designed specifically for socket fusion welding with a matching spigot end (male end). This type of connection allows for a strong, leak-proof, and permanent joint suitable for high-pressure pipelines in water supply, gas distribution, and industrial fluid systems.

Key Characteristics:

Material: High-Density Polyethylene (HDPE), typically PE63,PE80 or PE100 grade.
Design:
- One end of the pipe or fitting is expanded into a socket (female) form, sized precisely to accept a matching spigot end.
- The inner diameter of the socket is slightly larger than the outer diameter of the mating pipe to allow for proper fusion.
Joining Method:
- Socket fusion welding is performed by heating both the socket and spigot surfaces with a special fusion tool, then pressing them together to create a homogeneous, monolithic joint.
Sizes: Typically available in small to medium diameters ( DN20 to DN110), where socket fusion is most efficient.
Pressure Rating: Matches SDR class of the system, SDR11 (PN16), SDR17 (PN10), etc.

Applications:

Potable water distribution
Gas transmission
Irrigation systems
Industrial and chemical pipelines
Compressed air (low pressure)
Sewage and drainage systems

Advantages of HDPE Socket Pipe End:

Provides a leak-free joint without the need for gaskets or adhesives
Excellent resistance to corrosion, abrasion, and chemicals
Lightweight and easy to handle and install
Long service life over 50 years under proper conditions
Ideal for confined or trenchless installations due to minimal joint size

Technical Details
